Yale Unity Kit, Matt Black - 2 Smart Locks, Keypad 2, Hub 2
At A Glance
At A Glance
DISPATCHSame Day Before 11am
PIN Code
Fingerprint
RFID Card
Yale Home App
Remote (Hub 2 Included)
Voice
Face / PalmNot Available
The Yale Unity ALL-in-One Entrance Lock Kit (YUR/ENT/KIT2/MBK) is a complete smart lock system designed for Australian homes with a security screen door and a main entrance door. The kit delivers DualDoor Technology - a single credential action at the screen door simultaneously unlocks both the screen door and the main door behind it, removing the second unlock step entirely.
Everything needed for the system is included in the box: the Unity screen door lock, the Unity entrance lock, a Yale Smart Keypad 2 and the Yale Connect Plus Hub 2. From the moment the system is installed, full remote access and management are available through the Yale Home App without needing to purchase any additional hardware. Voice assistant integration with Amazon Alexa and Google Assistant is also supported.
Access credentials are managed through the Yale Home App. The kit is tested to Australian Standard and is intended for residential installation. If your home has a triple-locking screen door, check compatibility before ordering - see our guide on triple lock kit compatibility - cables vs rods for background on what to look for.
Estimated Dispatch
Usually ships same day if ordered before 11am AEST (excludes weekends and Queensland public holidays).
Usually ships same day if ordered before 11am AEST (excludes weekends and Queensland public holidays).
What Is DualDoor Technology?
DualDoor links the screen door lock and main entrance lock so that a single PIN, card tap, or app action releases both simultaneously. One step, both doors unlocked - no second handle, no second credential. For a plain-English explanation of how it works and who it suits, see What Dual Unlock Actually Does. To compare the Yale all-in-one approach with the McGrath modular approach, see McGrath vs Yale - Which Approach Suits You?
DualDoor links the screen door lock and main entrance lock so that a single PIN, card tap, or app action releases both simultaneously. One step, both doors unlocked - no second handle, no second credential. For a plain-English explanation of how it works and who it suits, see What Dual Unlock Actually Does. To compare the Yale all-in-one approach with the McGrath modular approach, see McGrath vs Yale - Which Approach Suits You?
Check Clearance Before Ordering
The screen door must be able to close freely in front of the main door lock. If the gap between your screen door and main door lock is smaller than the main door lock's projection, the screen door cannot close properly. Always measure this clearance before ordering. See Check the Clearance Between Door & Security Screen.
The screen door must be able to close freely in front of the main door lock. If the gap between your screen door and main door lock is smaller than the main door lock's projection, the screen door cannot close properly. Always measure this clearance before ordering. See Check the Clearance Between Door & Security Screen.
Looking for a more modular Dual Unlock option?
The McGrath UltraSecua Dual Unlock offers the same single-action dual-door unlocking, letting you choose your own main door lock and gateway separately. The Yale Unity Kit is the all-in-one approach; the McGrath is the modular approach. For a side-by-side comparison, see McGrath vs Yale - Which Approach Suits You?
The McGrath UltraSecua Dual Unlock offers the same single-action dual-door unlocking, letting you choose your own main door lock and gateway separately. The Yale Unity Kit is the all-in-one approach; the McGrath is the modular approach. For a side-by-side comparison, see McGrath vs Yale - Which Approach Suits You?
Key Features
- DualDoor Technology: A single PIN, card tap, or app unlock simultaneously releases the security screen door and the main entrance door. No second step required. For a full explanation, see our guide on how Dual Unlock works.
- Complete kit - nothing else required: The box includes the Unity screen door lock, Unity entrance lock, Yale Smart Keypad 2 and Yale Connect Plus Hub 2. Remote access is available from day one.
- Wi-Fi remote access included: The Connect Plus Hub 2 connects the system to your 2.4 GHz network, enabling remote lock management, credential management, and audit trail access from anywhere via the Yale Home App.
- Smart Keypad 2 for PIN and fingerprint entry: The included Smart Keypad 2 provides PIN code and fingerprint access without using your phone - convenient for household members, guests, and tradespeople.
- Mifare Classic RFID card access: Card-key access using the included Mifare Classic credentials - tap to unlock.
- Voice assistant integration: Compatible with Amazon Alexa and Google Assistant for voice-controlled locking and unlocking.
- Bluetooth connectivity: Local Bluetooth control via the Yale Home App without requiring an internet connection for day-to-day operation.
- Programmable access rights: Manage multiple users with individual access schedules, and view a full audit trail of who accessed the lock and when.
- Break-in and tamper alarm: Onboard alarm triggers on tampering or forced entry attempts.
- Reversible handing: Suits both left-hand and right-hand opening screen doors without ordering a separate variant.
- Tested to Australian Standard: The system has been tested to the applicable Australian standard for residential smart lock hardware (what Australian lock standards mean).
Access Methods
For a detailed explanation of each access method, see Chapter 03 - Smart Lock Access Methods.
Palm / Face Recognition
What's in the Box
- Yale Unity screen door lock assembly
- Yale Unity main entrance lock assembly
- Yale Smart Keypad 2
- Yale Connect Plus Hub 2 (2.4 GHz)
- Mifare Classic RFID access cards
- Mounting screws and fixings
- Installation guide
No separate gateway or Wi-Fi bridge purchase is required. The Connect Plus Hub 2 is included and enables remote access from day one.
Suitable Uses
- Homes with a security screen door and main entrance door: The defining application. DualDoor eliminates the two-step unlock that most screen door homes require. For a full explanation, see our guide on how Dual Unlock works.
- Buyers who want a complete, ready-to-install system: With both locks, the Smart Keypad 2, and the Connect Plus Hub 2 all in one box, no additional components need to be selected or purchased. Remote access is available from day one.
- Households with multiple regular users: Programmable access rights allow individual users to be assigned specific access schedules, with a full audit trail visible in the Yale Home App.
- Smart home environments: Alexa and Google Assistant integration allows voice-controlled locking and unlocking as part of a broader smart home setup.
- Properties where remote access is required from day one: The Connect Plus Hub 2 is included, so remote lock management is available immediately after installation. See Chapter 08 - Smart Lock Gateway Comparison for how this compares to gateway-based approaches.
- Single-point hinged screen door installations: The Unity screen door lock is designed for hinged security screen doors. For screen doors with triple-locking kits, check cable vs rod compatibility before ordering - see our triple lock compatibility guide for what to look for.
Not suitable for
Sliding screen doors - the Unity screen door lock is designed for hinged security screen doors. Triple-locking screen doors whose kit links the top and bottom locking points with flexible cables are generally not compatible with screen door smart locks, so check before ordering (cables vs rods). Always measure the screen door clearance first.
Sliding screen doors - the Unity screen door lock is designed for hinged security screen doors. Triple-locking screen doors whose kit links the top and bottom locking points with flexible cables are generally not compatible with screen door smart locks, so check before ordering (cables vs rods). Always measure the screen door clearance first.
Available Finish Options
Matt Black
(This Product)
STK YUR/ENT/KIT2/MBK
This kit is listed in Matt Black. For Silver, the locks are sold separately - see the Unity Entrance Lock (Silver) and Unity Screen Door Lock with Hub 2 (Silver).
Yale Unity DualDoor Options
Installation & Compatibility
- Designed for hinged security screen doors. Not suitable for sliding screen doors.
- Reversible handing - suits both left-hand and right-hand opening doors without ordering a separate handed version (door handing explained).
- Wi-Fi connectivity requires a 2.4 GHz network (802.11b/g/n). 5 GHz networks are not supported.
- Voice assistant integration (Alexa, Google Assistant) requires the relevant voice assistant device and the Yale Home App to be set up and linked.
- Always check the clearance between your security screen and main door before ordering. The main door lock projects from the door face, and the screen door must pass in front of it freely. See Check the Clearance Between Door & Security Screen for the measurement process. See also Chapter 02 - Measuring Your Door.
- For door type compatibility guidance, see Chapter 04 - Smart Lock Door Types.
- For the full specifications of each lock, see the Matt Black lock-only listings: the Unity Entrance Smart Lock and the Unity Security Screen Door Lock.
Specifications
Battery & Power
- Powered by AA alkaline batteries.
- Typical battery life up to 12 months under normal residential use.
- Low battery indicator alerts in the Yale Home App and audibly at the lock before batteries are depleted.
- The included Smart Keypad 2 runs on its own 4 x AAA batteries, rated at about 6 months (Smart Keypad 2 page, catalogue page 17).
- Terry's recommends using Duracell batteries when replacements are required. Do not mix old and new batteries.
Frequently Asked Questions
Does the kit include everything I need for remote access, or do I need to buy a gateway separately?
Everything is included. The Yale Connect Plus Hub 2 - which provides remote access and management via the Yale Home App - is included in the kit. No additional gateway or bridge purchase is needed. This is the primary advantage of the Yale all-in-one approach over modular alternatives.
Everything is included. The Yale Connect Plus Hub 2 - which provides remote access and management via the Yale Home App - is included in the kit. No additional gateway or bridge purchase is needed. This is the primary advantage of the Yale all-in-one approach over modular alternatives.
What is DualDoor Technology and how is it different from having two separate smart locks?
DualDoor links the screen door lock and the main entrance lock so that a single action - one PIN, one card tap, or one app command - releases both locks simultaneously. With two separate smart locks, each would need to be operated independently. DualDoor removes the second step entirely. For a detailed explanation, see our guide on What Dual Unlock Actually Does.
DualDoor links the screen door lock and the main entrance lock so that a single action - one PIN, one card tap, or one app command - releases both locks simultaneously. With two separate smart locks, each would need to be operated independently. DualDoor removes the second step entirely. For a detailed explanation, see our guide on What Dual Unlock Actually Does.
Will this work with my triple-locking security screen door?
Potentially, but triple-locking screen installations require additional checks before ordering. The key factor is whether your existing triple lock kit uses rigid rods or flexible cables to link the centre lock to the top and bottom locking points - cable-based kits are generally not compatible with screen door smart locks. See our guide on cables vs rods - the key rule before ordering, and contact Terry's if you are unsure.
Potentially, but triple-locking screen installations require additional checks before ordering. The key factor is whether your existing triple lock kit uses rigid rods or flexible cables to link the centre lock to the top and bottom locking points - cable-based kits are generally not compatible with screen door smart locks. See our guide on cables vs rods - the key rule before ordering, and contact Terry's if you are unsure.
Does the kit include fingerprint access?
Yes. The kit's keypad is the Yale Smart Keypad 2, which adds fingerprint recognition alongside PIN entry, so no separate keypad upgrade is needed. Credential types are compared in Chapter 03 - fingerprint.
Yes. The kit's keypad is the Yale Smart Keypad 2, which adds fingerprint recognition alongside PIN entry, so no separate keypad upgrade is needed. Credential types are compared in Chapter 03 - fingerprint.
Does the system work if the Wi-Fi drops out?
Yes. Bluetooth access via the Yale Home App continues to work locally without internet. PIN code entry via the Smart Keypad 2 and RFID card access also operate without any network connection. Remote features - remote unlock, remote credential management - require an active internet connection. For more on connectivity behaviour, see why smart locks sometimes drop off Wi-Fi.
Yes. Bluetooth access via the Yale Home App continues to work locally without internet. PIN code entry via the Smart Keypad 2 and RFID card access also operate without any network connection. Remote features - remote unlock, remote credential management - require an active internet connection. For more on connectivity behaviour, see why smart locks sometimes drop off Wi-Fi.
Additional Information
All-in-one vs modular
The Yale Unity kit is designed for buyers who want a complete, matched system with no component selection required. The alternative approach - buying a screen door smart lock separately and adding a main door lock and gateway - offers more flexibility in product choice but requires more decisions at purchase. The most direct modular alternative offering the same dual-door unlocking feature is the McGrath UltraSecua Dual Unlock, paired with a compatible McGrath main door lock. For a side-by-side comparison of the two approaches, see McGrath vs Yale - Which Approach Suits You?
The Yale Unity kit is designed for buyers who want a complete, matched system with no component selection required. The alternative approach - buying a screen door smart lock separately and adding a main door lock and gateway - offers more flexibility in product choice but requires more decisions at purchase. The most direct modular alternative offering the same dual-door unlocking feature is the McGrath UltraSecua Dual Unlock, paired with a compatible McGrath main door lock. For a side-by-side comparison of the two approaches, see McGrath vs Yale - Which Approach Suits You?
Screen door clearance - the most important pre-purchase check
When the screen door closes, it passes in front of the main entrance door and the lock on it. If the main door lock projects further from the door face than the gap between the two doors, the screen door cannot close. This is the most commonly missed pre-purchase check for any dual-door smart lock setup. See Check the Clearance Between Door & Security Screen for the measurement process.
When the screen door closes, it passes in front of the main entrance door and the lock on it. If the main door lock projects further from the door face than the gap between the two doors, the screen door cannot close. This is the most commonly missed pre-purchase check for any dual-door smart lock setup. See Check the Clearance Between Door & Security Screen for the measurement process.
Wi-Fi network requirement
The Connect Plus Hub 2 connects to 2.4 GHz networks only (802.11b/g/n). If your router broadcasts only at 5 GHz, a separate 2.4 GHz network or dual-band router configuration will be required. Most modern Australian routers support both bands - check your router settings if unsure. For more on smart lock Wi-Fi behaviour, see why smart locks sometimes drop off Wi-Fi.
The Connect Plus Hub 2 connects to 2.4 GHz networks only (802.11b/g/n). If your router broadcasts only at 5 GHz, a separate 2.4 GHz network or dual-band router configuration will be required. Most modern Australian routers support both bands - check your router settings if unsure. For more on smart lock Wi-Fi behaviour, see why smart locks sometimes drop off Wi-Fi.
Brand context
Yale is one of the world's longest-established lock brands, with a significant presence in the Australian residential smart lock market. For an overview of Yale's product range and how it sits relative to other brands in our range, see Chapter 10 - Smart Lock Brand Profiles.
Yale is one of the world's longest-established lock brands, with a significant presence in the Australian residential smart lock market. For an overview of Yale's product range and how it sits relative to other brands in our range, see Chapter 10 - Smart Lock Brand Profiles.
Warranty
Yale Warranty
Genuine Yale products bought new in Australia from authorised retailers are covered against defects in materials and workmanship for:
Genuine Yale products bought new in Australia from authorised retailers are covered against defects in materials and workmanship for:
- Mechanical parts: 10 years
- Electrical and electronic components: 3 years (batteries excluded)
- Keys: 12 months
Finishes, cosmetic wear, batteries, normal wear and tear, misuse, unauthorised modification and corrosion (including coastal air and salt spray) are excluded. Proof of purchase is required for all claims.
This warranty is in addition to your rights under the Australian Consumer Law.
Download PDF Resources
Yale Smart Locks Catalogue (PDF)
The full Australian Yale smart lock range (2025_09 edition). For this kit see DualDoor Technology on page 4, the Unity Entrance Series on page 8, the Unity Security Screen Door Lock on page 9 to 12, the Unity Entrance Lock on page 13 and page 14, the Smart Keypad 2 on page 17 and the Connect Plus Hub 2 on page 42.
The full Australian Yale smart lock range (2025_09 edition). For this kit see DualDoor Technology on page 4, the Unity Entrance Series on page 8, the Unity Security Screen Door Lock on page 9 to 12, the Unity Entrance Lock on page 13 and page 14, the Smart Keypad 2 on page 17 and the Connect Plus Hub 2 on page 42.
Yale Unity Entrance Lock Installation Guide (V12, 2022) (PDF)
The 12-step installation guide for the Unity entrance lock: tools, components and exploded view, door preparation, handing, the door position sensor and magnet, clutch alignment, furniture, batteries and the strike.
The 12-step installation guide for the Unity entrance lock: tools, components and exploded view, door preparation, handing, the door position sensor and magnet, clutch alignment, furniture, batteries and the strike.
Yale Unity Security Screen Door Lock Installation Guide (0621) (PDF)
The installation guide for the Unity screen door lock: components and exploded view, handing, preparing and fitting the central mortice, the door position sensor cable, furniture and batteries, plus the strike procedures for single-point and 3-point doors.
The installation guide for the Unity screen door lock: components and exploded view, handing, preparing and fitting the central mortice, the door position sensor cable, furniture and batteries, plus the strike procedures for single-point and 3-point doors.
Yale Smart Keypad 2 - Product Sheet (PDF)
Manufacturer product sheet for the Smart Keypad 2 (05/303000/BL): fingerprint or 4-8 digit code entry, up to 10 fingerprints, IP55 and 4 x AAA batteries. It is Yale's Middle East edition, so its compatibility list names other Yale products rather than the Australian Unity range; the catalogue's Smart Keypad 2 page covers Unity pairing.
Manufacturer product sheet for the Smart Keypad 2 (05/303000/BL): fingerprint or 4-8 digit code entry, up to 10 fingerprints, IP55 and 4 x AAA batteries. It is Yale's Middle East edition, so its compatibility list names other Yale products rather than the Australian Unity range; the catalogue's Smart Keypad 2 page covers Unity pairing.
Yale Connect Plus Hub 2 Brochure (PDF)
Two-page brochure for the Connect Plus Hub 2 (YAR/SWAA/HUB/-I-D): remote access through the Yale Home App, Alexa and Google Home support, one hub for up to 16 Bluetooth and 30 Zigbee devices, and the pairing and reset buttons. It is the New Zealand edition; use the catalogue page for the hub's dimensions.
Two-page brochure for the Connect Plus Hub 2 (YAR/SWAA/HUB/-I-D): remote access through the Yale Home App, Alexa and Google Home support, one hub for up to 16 Bluetooth and 30 Zigbee devices, and the pairing and reset buttons. It is the New Zealand edition; use the catalogue page for the hub's dimensions.
Yale Home App - Step by Step Guide (PDF)
Setting up and using the Yale Home App: several devices on one Connect Plus bridge (page 7), DualDoor setup (page 8), guest access, auto-unlock, auto-lock and door-ajar alerts, plus the Unity Entrance Series (page 25), Unity Security Screen Door Lock (page 26) and Unity Entrance Lock (page 27) FAQ pages.
Setting up and using the Yale Home App: several devices on one Connect Plus bridge (page 7), DualDoor setup (page 8), guest access, auto-unlock, auto-lock and door-ajar alerts, plus the Unity Entrance Series (page 25), Unity Security Screen Door Lock (page 26) and Unity Entrance Lock (page 27) FAQ pages.
Yale Home App Quick Start Guide (PDF)
A one-page card: download the Yale Home App and scan the QR code to start setting up the kit.
A one-page card: download the Yale Home App and scan the QR code to start setting up the kit.
Yale Warranty (Australia) (PDF)
ASSA ABLOY Australia's Yale warranty terms: 10 years on mechanical parts, 3 years on electrical and electronic components (batteries excluded), 12 months on keys, the exclusions (including coastal air and salt spray) and how to make a claim.
ASSA ABLOY Australia's Yale warranty terms: 10 years on mechanical parts, 3 years on electrical and electronic components (batteries excluded), 12 months on keys, the exclusions (including coastal air and salt spray) and how to make a claim.
Yale Unity Kit - FAQ, Setup and Owner's Guide
A deep reference for the Yale Unity ALL-in-One Entrance Lock Kit (Matt Black, YUR/ENT/KIT2/MBK) covering what is in the box, DualDoor, door fit and screen door compatibility, credentials, remote access, power and warranty. For general questions see Chapter 13 - Smart Lock FAQ and the Ultimate Smart Lock Buyer's Guide.
What Is in the Kit
What exactly comes in the box?
Two locks and the two smart accessories that tie them together: a Yale Unity screen door lock assembly, a Yale Unity main entrance lock assembly, a Yale Smart Keypad 2 and a Yale Connect Plus Hub 2, plus Mifare Classic RFID access cards, mounting screws and fixings, and an installation guide.
Two locks and the two smart accessories that tie them together: a Yale Unity screen door lock assembly, a Yale Unity main entrance lock assembly, a Yale Smart Keypad 2 and a Yale Connect Plus Hub 2, plus Mifare Classic RFID access cards, mounting screws and fixings, and an installation guide.
Which keypad is in the kit - the original Smart Keypad or the Smart Keypad 2?
The Smart Keypad 2 (05/303000/BL). It handles PIN codes and fingerprints, mounts outside with no hard-wiring and pairs with the Unity locks over Bluetooth. Yale's current catalogue lists the Unity packs with the Smart Keypad 2 (Smart Keypad 2 page).
The Smart Keypad 2 (05/303000/BL). It handles PIN codes and fingerprints, mounts outside with no hard-wiring and pairs with the Unity locks over Bluetooth. Yale's current catalogue lists the Unity packs with the Smart Keypad 2 (Smart Keypad 2 page).
Is the Wi-Fi bridge the Connect Plus Hub 2?
Yes. The kit's gateway is the Connect Plus Hub 2 (YAR/SWAA/HUB/-I-D), which links the locks to your 2.4 GHz Wi-Fi for remote access, voice assistants and DualDoor. One hub serves both locks in this kit. Gateways compared: Chapter 08 - what a gateway does.
Yes. The kit's gateway is the Connect Plus Hub 2 (YAR/SWAA/HUB/-I-D), which links the locks to your 2.4 GHz Wi-Fi for remote access, voice assistants and DualDoor. One hub serves both locks in this kit. Gateways compared: Chapter 08 - what a gateway does.
What finish is the kit?
Matt Black. For Silver, the locks are sold separately: the Unity Entrance Lock (Silver) and the Unity Screen Door Lock with Hub 2 (Silver).
Matt Black. For Silver, the locks are sold separately: the Unity Entrance Lock (Silver) and the Unity Screen Door Lock with Hub 2 (Silver).
DualDoor
What does DualDoor actually do?
One credential action at the screen door - a PIN, a card tap or an app command - releases both the screen door lock and the entrance lock behind it, so you walk through both doors without a second unlock. How it works in practice: how dual-door entry works.
One credential action at the screen door - a PIN, a card tap or an app command - releases both the screen door lock and the entrance lock behind it, so you walk through both doors without a second unlock. How it works in practice: how dual-door entry works.
Why choose DualDoor over two separate smart locks?
With two independent smart locks, each door is a separate step. DualDoor removes that second step entirely. Who it suits: who dual unlock is for, and what it does not do: the limits of dual unlock.
With two independent smart locks, each door is a separate step. DualDoor removes that second step entirely. Who it suits: who dual unlock is for, and what it does not do: the limits of dual unlock.
Is there a modular alternative?
Yes - the McGrath UltraSecua Dual Unlock offers the same single-action dual-door unlocking while you choose your own main door lock and gateway. Comparison: McGrath vs Yale.
Yes - the McGrath UltraSecua Dual Unlock offers the same single-action dual-door unlocking while you choose your own main door lock and gateway. Comparison: McGrath vs Yale.
Door Fit and Screen Door Compatibility
What must I measure before ordering?
The clearance between the screen door and the main door lock. The entrance lock projects from the door face and the screen door must close freely in front of it. Measure first: how to measure screen door clearance and Chapter 02 - screen clearance.
The clearance between the screen door and the main door lock. The entrance lock projects from the door face and the screen door must close freely in front of it. Measure first: how to measure screen door clearance and Chapter 02 - screen clearance.
Does it suit sliding screen doors?
No. The Unity screen door lock is designed for hinged security screen doors only. For other door types see Chapter 04 - screen doors.
No. The Unity screen door lock is designed for hinged security screen doors only. For other door types see Chapter 04 - screen doors.
Will it work with a triple-locking screen door?
Possibly. It depends on how the existing kit links the centre lock to the top and bottom points - rigid rods can work, flexible cables generally cannot. Check cables vs rods and the single-point alternative before ordering, or ask Terry's.
Possibly. It depends on how the existing kit links the centre lock to the top and bottom points - rigid rods can work, flexible cables generally cannot. Check cables vs rods and the single-point alternative before ordering, or ask Terry's.
Do I need a left- or right-hand version?
No. Handing is reversible, so the same kit suits left-hand and right-hand opening doors. Background: field-reversible handing.
No. Handing is reversible, so the same kit suits left-hand and right-hand opening doors. Background: field-reversible handing.
Where are the door thickness and backset figures?
Each lock has its own fit requirements. See the Matt Black lock-only pages for full door fit, dimensions and standards: the Unity Entrance Smart Lock and the Unity Security Screen Door Lock. How to measure: door thickness and backset.
Each lock has its own fit requirements. See the Matt Black lock-only pages for full door fit, dimensions and standards: the Unity Entrance Smart Lock and the Unity Security Screen Door Lock. How to measure: door thickness and backset.
Access and Credentials
What ways can I unlock?
PIN code and fingerprint at the Smart Keypad 2, a Mifare Classic RFID card tap, the Yale Home App over Bluetooth, remote unlock over Wi-Fi through the Hub 2, and Amazon Alexa or Google Assistant voice control. Palm and face recognition are not supported. Methods compared: Chapter 03.
PIN code and fingerprint at the Smart Keypad 2, a Mifare Classic RFID card tap, the Yale Home App over Bluetooth, remote unlock over Wi-Fi through the Hub 2, and Amazon Alexa or Google Assistant voice control. Palm and face recognition are not supported. Methods compared: Chapter 03.
What card format does the kit use?
Mifare Classic RFID cards, supplied in the kit - tap to unlock. RFID explained: Chapter 03 - RFID.
Mifare Classic RFID cards, supplied in the kit - tap to unlock. RFID explained: Chapter 03 - RFID.
Can I give different people different access?
Yes. Programmable access rights let you add multiple users with individual schedules, and the Yale Home App keeps a full audit trail of who accessed the lock and when. Platform overview: Chapter 15 - Yale Home.
Yes. Programmable access rights let you add multiple users with individual schedules, and the Yale Home App keeps a full audit trail of who accessed the lock and when. Platform overview: Chapter 15 - Yale Home.
Which voice assistants work?
Amazon Alexa and Google Assistant, for voice-controlled locking and unlocking. Each needs its voice assistant device and the Yale Home App set up and linked.
Amazon Alexa and Google Assistant, for voice-controlled locking and unlocking. Each needs its voice assistant device and the Yale Home App set up and linked.
Remote Access and Wi-Fi
What Wi-Fi does the hub need?
A 2.4 GHz network (802.11b/g/n); 5 GHz is not supported. If your router broadcasts only at 5 GHz, set up a 2.4 GHz network or a dual-band configuration. If the lock drops off, see band steering and dropouts and gateway placement.
A 2.4 GHz network (802.11b/g/n); 5 GHz is not supported. If your router broadcasts only at 5 GHz, set up a 2.4 GHz network or a dual-band configuration. If the lock drops off, see band steering and dropouts and gateway placement.
What still works if the internet goes down?
Bluetooth access through the Yale Home App, PIN and fingerprint entry at the Smart Keypad 2 and RFID card access all work locally. Remote unlock and remote credential changes need the internet. More: when the internet is down.
Bluetooth access through the Yale Home App, PIN and fingerprint entry at the Smart Keypad 2 and RFID card access all work locally. Remote unlock and remote credential changes need the internet. More: when the internet is down.
Power, Security and Warranty
What batteries do the locks use?
AA alkaline batteries, typically up to 12 months under normal residential use, with a low battery indicator in the Yale Home App and audibly at the lock before they are depleted. The Smart Keypad 2 runs on its own 4 x AAA batteries. Terry's recommends Duracell and not mixing old and new batteries. Battery realities: the realities of electronic door locks.
AA alkaline batteries, typically up to 12 months under normal residential use, with a low battery indicator in the Yale Home App and audibly at the lock before they are depleted. The Smart Keypad 2 runs on its own 4 x AAA batteries. Terry's recommends Duracell and not mixing old and new batteries. Battery realities: the realities of electronic door locks.
Is the tamper alarm genuine?
Yes. The onboard break-in and tamper alarm triggers on tampering or forced entry attempts. Yale is an ASSA ABLOY brand, not a TTLock lock. Background: tamper alerts and phantom alerts.
Yes. The onboard break-in and tamper alarm triggers on tampering or forced entry attempts. Yale is an ASSA ABLOY brand, not a TTLock lock. Background: tamper alerts and phantom alerts.
What standards is it tested to?
The system has been tested to the applicable Australian standard for residential smart lock hardware. It is not fire rated and not a DDA (AS1428.1) product. Standards explained: Chapter 11 - AS4145.
The system has been tested to the applicable Australian standard for residential smart lock hardware. It is not fire rated and not a DDA (AS1428.1) product. Standards explained: Chapter 11 - AS4145.
What warranty applies?
Yale covers the kit for 10 years on mechanical parts and 3 years on electrical and electronic components, with batteries excluded. Proof of purchase is required. Returns and warranty.
Yale covers the kit for 10 years on mechanical parts and 3 years on electrical and electronic components, with batteries excluded. Proof of purchase is required. Returns and warranty.
Related Yale Products, Guides and Buyer's Guide Chapters
Kit components sold separately: Unity Entrance (Matt Black) | Unity Entrance (Silver) | Screen Door (Matt Black) | Screen Door (Silver) | Screen Door + Hub 2 (Matt Black) | Screen Door + Hub 2 (Silver) | Screen Door Mortice Only | Smart Keypad 2 | Connect Plus Hub 2.
Categories: Hinged security screen door smart locks | Front door smart locks | Keypads for smart locks | Modules and Wi-Fi gateways.
Buyer's Guide chapters: 02 Measuring Your Door | 03 Access Methods | 04 Door Types | 08 Gateways | 10 Yale Brand Profile | 11 Australian Standards | 12 Installation and Troubleshooting | 13 Smart Lock FAQ | 15 App Platforms.
Guides and blogs: Dual Unlock explained | Check screen door clearance | Triple lock kits - what works | Why smart locks drop off Wi-Fi | Yale smart locks - an honest assessment | Which app platform is right for you | Realities of electronic door locks | How long do digital locks last | Door handing in Australia | 3 DIY installation mistakes | Tamper alert and phantom alerts | Smart locks and the new cyber security law | Site survey and installation.
Yale Unity Kit - What's in the Box
- Yale Unity screen door lock assembly
- Yale Unity main entrance lock assembly
- Yale Smart Keypad 2
- Yale Connect Plus Hub 2 (2.4 GHz)
- Mifare Classic RFID access cards
- Mounting screws and fixings
- Installation guide
Gateway included
The Connect Plus Hub 2 is included - no separate gateway purchase is required to enable remote access.
The Connect Plus Hub 2 is included - no separate gateway purchase is required to enable remote access.
PDF Files - Yale Unity Kit, Matt Black
Yale Smart Locks Catalogue (PDF)
The full Australian Yale smart lock range (2025_09 edition). For this kit see DualDoor Technology on page 4, the Unity Entrance Series on page 8, the Unity Security Screen Door Lock on page 9 to 12, the Unity Entrance Lock on page 13 and page 14, the Smart Keypad 2 on page 17 and the Connect Plus Hub 2 on page 42.
The full Australian Yale smart lock range (2025_09 edition). For this kit see DualDoor Technology on page 4, the Unity Entrance Series on page 8, the Unity Security Screen Door Lock on page 9 to 12, the Unity Entrance Lock on page 13 and page 14, the Smart Keypad 2 on page 17 and the Connect Plus Hub 2 on page 42.
Yale Unity Entrance Lock Installation Guide (V12, 2022) (PDF)
The 12-step installation guide for the Unity entrance lock: tools, components and exploded view, door preparation, handing, the door position sensor and magnet, clutch alignment, furniture, batteries and the strike.
The 12-step installation guide for the Unity entrance lock: tools, components and exploded view, door preparation, handing, the door position sensor and magnet, clutch alignment, furniture, batteries and the strike.
Yale Unity Security Screen Door Lock Installation Guide (0621) (PDF)
The installation guide for the Unity screen door lock: components and exploded view, handing, preparing and fitting the central mortice, the door position sensor cable, furniture and batteries, plus the strike procedures for single-point and 3-point doors.
The installation guide for the Unity screen door lock: components and exploded view, handing, preparing and fitting the central mortice, the door position sensor cable, furniture and batteries, plus the strike procedures for single-point and 3-point doors.
Yale Smart Keypad 2 - Product Sheet (PDF)
Manufacturer product sheet for the Smart Keypad 2 (05/303000/BL): fingerprint or 4-8 digit code entry, up to 10 fingerprints, IP55 and 4 x AAA batteries. It is Yale's Middle East edition, so its compatibility list names other Yale products rather than the Australian Unity range; the catalogue's Smart Keypad 2 page covers Unity pairing.
Manufacturer product sheet for the Smart Keypad 2 (05/303000/BL): fingerprint or 4-8 digit code entry, up to 10 fingerprints, IP55 and 4 x AAA batteries. It is Yale's Middle East edition, so its compatibility list names other Yale products rather than the Australian Unity range; the catalogue's Smart Keypad 2 page covers Unity pairing.
Yale Connect Plus Hub 2 Brochure (PDF)
Two-page brochure for the Connect Plus Hub 2 (YAR/SWAA/HUB/-I-D): remote access through the Yale Home App, Alexa and Google Home support, one hub for up to 16 Bluetooth and 30 Zigbee devices, and the pairing and reset buttons. It is the New Zealand edition; use the catalogue page for the hub's dimensions.
Two-page brochure for the Connect Plus Hub 2 (YAR/SWAA/HUB/-I-D): remote access through the Yale Home App, Alexa and Google Home support, one hub for up to 16 Bluetooth and 30 Zigbee devices, and the pairing and reset buttons. It is the New Zealand edition; use the catalogue page for the hub's dimensions.
Yale Home App - Step by Step Guide (PDF)
Setting up and using the Yale Home App: several devices on one Connect Plus bridge (page 7), DualDoor setup (page 8), guest access, auto-unlock, auto-lock and door-ajar alerts, plus the Unity Entrance Series (page 25), Unity Security Screen Door Lock (page 26) and Unity Entrance Lock (page 27) FAQ pages.
Setting up and using the Yale Home App: several devices on one Connect Plus bridge (page 7), DualDoor setup (page 8), guest access, auto-unlock, auto-lock and door-ajar alerts, plus the Unity Entrance Series (page 25), Unity Security Screen Door Lock (page 26) and Unity Entrance Lock (page 27) FAQ pages.
Yale Home App Quick Start Guide (PDF)
A one-page card: download the Yale Home App and scan the QR code to start setting up the kit.
A one-page card: download the Yale Home App and scan the QR code to start setting up the kit.
Yale Warranty (Australia) (PDF)
ASSA ABLOY Australia's Yale warranty terms: 10 years on mechanical parts, 3 years on electrical and electronic components (batteries excluded), 12 months on keys, the exclusions (including coastal air and salt spray) and how to make a claim.
ASSA ABLOY Australia's Yale warranty terms: 10 years on mechanical parts, 3 years on electrical and electronic components (batteries excluded), 12 months on keys, the exclusions (including coastal air and salt spray) and how to make a claim.
Yale Warranty
Yale branded products are manufactured and warranted in Australia by ASSA ABLOY Australia Pty Ltd. Coverage is tiered by component type - mechanical parts, electrical and electronic components, and keys each carry their own warranty period. The summary below sets out each period, what is excluded, and how to make a claim through Gold Coast Smart Locks.
This warranty applies to genuine Yale products purchased new in Australia from ASSA ABLOY or its authorised resellers. It operates in addition to your rights under the Australian Consumer Law.
Warranty Summary
How to Make a Claim
Start your claim with us
For full returns and warranty claim procedures, visit our Returns & Warranty page - this is kept up to date and is the authoritative reference for current claim steps.
For full returns and warranty claim procedures, visit our Returns & Warranty page - this is kept up to date and is the authoritative reference for current claim steps.
- Keep your proof of original purchase (invoice or receipt).
- Contact Gold Coast Smart Locks - operated by Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries - as your authorised retailer, and follow the steps on our Returns & Warranty page.
- Return the product securely packed to protect it in transit, together with your proof of purchase and your name, address, email and phone number.
- ASSA ABLOY assesses the claim. Where the warranty applies, they will (at their option) repair the product, replace it with the same or closest equivalent Yale product, or refund the price you paid.
Claims made directly to ASSA ABLOY require a Case Number from their Customer Service Department before goods are returned - products sent back without a Case Number may not be accepted. Costs of returning a product are the customer's responsibility.
What Is Not Covered
- Normal wear and tear.
- Misuse, abuse, accident, or use outside Yale's published technical specifications.
- Improper maintenance or neglect, or failure to follow ASSA ABLOY's care and maintenance recommendations.
- Use of batteries other than those specified; batteries themselves are not covered.
- Unauthorised alteration, modification or repair by anyone other than ASSA ABLOY authorised personnel.
- Custom orders made to components or specifications supplied by someone other than ASSA ABLOY.
- Goods that were not new when purchased, second-hand goods, or products not originally sold in Australia through ASSA ABLOY or an authorised reseller.
- Products with brands, marks, plates, numbers or other ASSA ABLOY information defaced or removed.
- Use of substitute, replacement or non-genuine ASSA ABLOY parts or cylinders.
- Corrosive exposure, including vapours, chemicals, abrasive compounds, contamination, pollution, coastal air, salt spray and high humidity.
- Removal, refitment or replacement of products, and any associated charges.
Important Notes
Batteries, finishes and stainless steel
Batteries are consumable and are not covered. Cosmetic finishes and appearance are excluded. Stainless steel resists staining but is not stain-proof - tea staining is a natural process and is not covered where cleaning and maintenance guidelines have not been followed.
Batteries are consumable and are not covered. Cosmetic finishes and appearance are excluded. Stainless steel resists staining but is not stain-proof - tea staining is a natural process and is not covered where cleaning and maintenance guidelines have not been followed.
Coastal and corrosive environments
Damage from salt spray, coastal air, high humidity and other corrosives is excluded. In Gold Coast and coastal locations, choose a suitable finish and follow the care and maintenance guidance to protect your hardware and preserve your cover.
Damage from salt spray, coastal air, high humidity and other corrosives is excluded. In Gold Coast and coastal locations, choose a suitable finish and follow the care and maintenance guidance to protect your hardware and preserve your cover.
Your Rights Under the Australian Consumer Law
In addition to this warranty
This manufacturer's warranty is in addition to other rights and remedies you may have under the law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and to compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure.
This manufacturer's warranty is in addition to other rights and remedies you may have under the law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and to compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure.
Further Information
Further Information
Returns & Warranty - goldcoastsmartlocks.com.au
Download the Yale Warranty (PDF)
Official Yale warranty terms - yalehome.com.au
Manufacturer: ASSA ABLOY Australia Pty Ltd, 235 Huntingdale Road, Oakleigh VIC 3166. Tel: 1300WARRANTY. Email: 1300warranty@assaabloy.com
Returns & Warranty - goldcoastsmartlocks.com.au
Download the Yale Warranty (PDF)
Official Yale warranty terms - yalehome.com.au
Manufacturer: ASSA ABLOY Australia Pty Ltd, 235 Huntingdale Road, Oakleigh VIC 3166. Tel: 1300WARRANTY. Email: 1300warranty@assaabloy.com
Confused? Overwhelmed? We get it.
Choosing the right smart lock can be genuinely tricky - door types, backsets, app platforms, compatibility with your existing hardware... there is a lot to consider. We have decades of experience fitting locks of all types, including smart locks, and we are happy to help.
Our expert recommendation service is free. Upload a few photos of your door and describe what you need, and one of our qualified locksmiths will give you a personalised recommendation.
Get Your Free Recommendation →How it works - three easy steps:
1. Upload photos
A few clear shots of your door, lock and frame - inside and out.
2. We assess
Our locksmith reviews your setup and requirements - door type, weather exposure, how you want to use it.
3. You get a recommendation
A personalised recommendation tailored to your door, budget and needs. No pressure, no upsell.
Also useful while you are deciding:
