Carbine CDL2 Digital Lever Lock with PIN and Key Override - Satin Nickel and Matte Black Kit with Batteries
At A Glance
At A Glance
DISPATCHSame Day Before 11am AEST
PIN Code
Mechanical Key
RFID / FobNot Available
BluetoothNot Available
App AccessNot Available
The Carbine CDL2 Digital Leverset (CDL2-SL8) provides simple PIN code access and mechanical key override in a compact, slimline membrane keypad design. Available in Satin Nickel (CDL2-SL8SNKIT) and Matte Black (CDL2-SL8MBKIT) - both finishes sold from this page.
Uses a membrane keypad (not a touchscreen), stores up to 20 user codes (4-8 digits), and is powered by 4 x AAA batteries. Auto-lock mode is controlled by the interior thumbturn: horizontal = auto-lock active; vertical = passage mode.
PIN-only lock - no RFID, no Bluetooth. For RFID, see the CEL-3IN1-SL8-SNKIT. For Bluetooth, see the CEL2-BT-SL8SNKIT. For the CDL2 deadbolt, see the CDL2-DB.
See: Buyers Guide Ch03: Smart Lock Access Methods · How long do digital door locks last? · Buyers Guide Ch10: Carbine brand profile · Carbine CEL & CDL Buyer's Guide - CDL2 Leverset
Usually ships same day if ordered before 11am AEST (excludes weekends and Queensland public holidays).
Available Finish Options
Satin Nickel
(This Product)
CDL2-SL8SNKIT
Matte Black
(This Product)
CDL2-SL8MBKIT
Both finishes sold from this page. Finish does not affect functionality or performance.
Key Features
- Membrane keypad (not touchscreen) - slimline design with smaller footprint.
- Stores 20 user codes (4-8 digits) plus 1 programming code (default 123456).
- Lever height projects 65mm from the door surface (NCC compliant SL8 lever).
- Auto-lock controlled by interior thumbturn: horizontal = auto-lock; vertical = passage mode.
- Ships as Right Swing by default; field-reversible to Left Swing. See: Understanding door handing in Australia
- Keypad locks out after 4 consecutive incorrect entries.
- Vacation mode temporarily disables all user codes.
- Fits standard 54mm lockset hole; door 35-51mm; backset 60-70mm adjustable. Cannot use 127mm backset latches.
- LKW9 (Silca LW5) keyway, 6-pin cylinder, keyed to 5-pin key.
- 4 x AAA batteries (note: AAA, not AA). Included in KIT.
- Cycle tested to 250,000 operations. Moisture and salt spray tested. See: Lockwood vs Borg vs Carbine - corrosion
- No RFID; no Bluetooth; not fire rated.
- Keypad volume is adjustable through the programming menu.
- User codes can be deleted individually, or cleared all at once.
Access Methods
Face Recognition
Palm Recognition
Suitable Uses
- Residential doors requiring simple, keyless PIN code access without RFID or app connectivity.
- Rental properties requiring straightforward code management with no smartphone dependency. See: before you buy a digital door lock
- Internal doors, laundry rooms, garages, or outbuildings where PIN access only is needed.
- Doors where field-reversible handing is required - ships Right Swing, reversible to Left Swing in the field. See: Ch02: Door handing explained
- See also: Buyers Guide Ch04: Smart Lock Door Types
See also: Check clearance between door and security screen · Understanding door handing in Australia · Buyers Guide Ch02: Measuring Your Door · Advice and Installation
What's in the Box
- 1 x exterior module with membrane keypad
- 1 x interior lever housing with thumbturn
- 1 x tubular latch (60-70mm adjustable backset)
- 1 x LKW9 (Silca LW5) keyway cylinder
- 2 x mechanical keys
- 1 x user manual and installation guide
- 1 x set of fixing screws (27mm, 20.5mm and 19mm)
- 4 x AAA alkaline batteries (Duracell Procell)
Carbine CEL / CEL2 / CDL2 - Complete Product Family
CEL2-BT deadbolt: RFID not compatible - Bluetooth and PIN only. CDL2 models: membrane keypad, no RFID. All KIT numbers include batteries. For a full model comparison: Carbine CEL & CDL Buyer's Guide - CDL2 Leverset · the range at a glance · browse the full Carbine range
Full Specifications
Dimensions
Battery, Power & Backup Access
- Powered by 4 x AAA alkaline batteries (Duracell Procell recommended). Note: CDL2 leverset uses AAA - different from CEL/CEL2 which use AA batteries.
- Low battery warning via indicator light before full depletion.
- The low battery signal is a yellow button light, and the indicator flashes red and green four times with four beeps when a code is entered.
- Mechanical key override via LKW9 cylinder keys - always keep a key stored securely off-site. See: where to keep the override key
- This KIT version includes batteries. See: How long do digital door locks last? · Ch13: power and battery questions
Frequently Asked Questions
The CDL2 is PIN-only with a membrane keypad. The CEL-3IN1 is a touchscreen lock accepting RFID cards, FOBs, and NFC phones in addition to PIN. The CDL2 uses 4 x AAA batteries; the CEL-3IN1 uses 4 x AA. The CDL2 is simpler and lower cost. See: Carbine CEL & CDL Buyer's Guide - CDL2 vs CEL
Auto-lock is controlled by the interior thumbturn position. Horizontal = auto-lock active. Vertical = passage mode (functions as a passage lever with no auto-lock). This differs from the CEL series which uses a timed auto-lock via programming.
The CDL2 leverset uses 4 x AAA alkaline batteries (not AA - different from the CEL/CEL2 series). Low battery warning via indicator light before full depletion. See: How long do digital door locks last? · Ch13: power and battery
Yes. The CDL2 leverset ships Right Swing by default and can be changed to Left Swing in the field without additional parts. See: Understanding door handing in Australia and the Installation Specs tab for the handing change procedure.
This lock requires 35-51mm door thickness and 60-70mm backset. Outside these ranges it is not compatible. See: Buyers Guide Ch02: Backset · How to measure your backset
Additional Information
The CDL2 leverset uses 4 x AAA batteries - not AA. Keep spare AAA batteries on hand. Do not substitute with lithium or rechargeable (NiMH) batteries. See: The realities of electronic door locks - battery life
Clean with mild soap and a soft cloth only. Do not use chemicals containing alcohol, benzene, or acids. Do not use sharp or abrasive objects on the keypad.
The three most common installation problems are: incorrect latch backset setting, spindle misalignment, and a loose or damaged cable connection between the exterior and interior modules. See: 3 common DIY smart lock installation mistakes and how to fix them · Buyers Guide Ch12: Troubleshooting
The CDL2 leverset uses a spring-loaded tubular latch (not a deadbolt). The latch retracts when the lever is pressed and auto-locks when the door closes. If you need secondary deadbolt security, see the CDL2-DB digital deadbolt. Not sure which you need? What is bolt throw and why does it matter? · Secondary locks and the one-penetration principle
The template marks a 54mm bore, a 25mm edge hole and door thicknesses of 35, 40, 45 and 51mm, with separate 60mm and 70mm backset positions. Three screw lengths are supplied - 27mm, 20.5mm and 19mm - so check you have the right one before you start. The connecting cable seats with the metal side facing outward, and a drive-in latch option is covered in the installation sheet. See: Carbine CDL2 Leverset Installation Guide (PDF) · Advice and Installation
Warranty
Carbine products are backed by Davcor Group Pty Ltd, the Australian manufacturer and owner of the Carbine brand, distributed locally through Lock and Key Co. Warranty periods vary by product category:
- Up to 15 years - mechanical hardware, door hardware, cabinet furniture, utility and window locks
- 10 years - padlocks and mechanical digital locks
- 5 years - cylinders and keys
- 12 months - electronic and digital locks, locksmith tools and supplies
Download PDF Resources
Everyday use and programming - auto-lock and passage mode via the thumbturn, 20 user codes (4-8 digits), keypad lockout after 4 wrong entries, vacation mode, volume and troubleshooting, including the low battery warning.
Parts and screws, door preparation template (54mm bore, 60mm or 70mm backset), strike and jamb dimensions, cable connection and how to change the handing - the lock ships set for right swing doors.
Carbine's problem, cause and fix tables for its CEL-3in1 leverset and deadbolt - unresponsive keypad, battery and cable tips, programming problems, deadbolt handing and factory reset. Written for the CEL-3in1 range; it does not name the CDL2.
Carbine CDL2 Digital Leverset - FAQ, Setup and Owner's Guide
Everything buyers, installers and owners ask us about the CDL2-SL8. For the wider picture, see Buyers Guide Chapter 13: Smart Lock FAQ and the Smart Lock Buyer's Guide.
Access, Codes and Programming
Twenty user codes, each 4 to 8 digits long, plus one programming code. That is double the ten codes the CDL2 deadbolt holds, and the two models are not interchangeable on capacity. If you need more than twenty, the CEL2-3IN1 leverset carries a hundred codes and cards in one shared pool. More on how PIN access works: Buyers Guide Ch03.
The default programming code is 123456, and yes - change it before the lock goes into service. It is printed in the CDL2 Leverset User Guide, so anyone who knows the model knows the code. Note that the CDL2 uses a six-digit default; the CEL and CEL2 ranges use an eight-digit 12345678, so do not follow a CEL guide on this lock.
Yes. Individual user codes can be deleted one at a time from the keypad, and there is a separate command to clear every user code at once. That makes the CDL2 practical for a rental or a shared office where one person's access needs to end without disturbing everyone else's. The full sequence is in the User Guide.
The keypad locks out after four consecutive incorrect entries. It is a simple deterrent rather than an audit trail - the CDL2 has no app and keeps no event log, so if you need to know who opened the door and when, you need an app-connected lock such as the CEL2-BT leverset on Carbine Connect.
Yes - keypad volume is adjustable from the programming menu, which is worth knowing on a bedroom, apartment or shift-worker door where a full-volume beep at 5am is not welcome. The setting is covered in the CDL2 Leverset User Guide.
It switches every user code off for a period, then switches them back on, without deleting anything. Codes survive the holiday and go on working when you return. Useful on a holiday unit or a house left empty, and it pairs well with keeping the mechanical key with someone you trust locally - see where to keep the override key.
Auto-Lock, Passage Mode and Everyday Use
You turn the interior thumbturn. Horizontal is auto-lock on; vertical is passage mode. There is no timer to program and no app to open - it is a physical position you can see at a glance, which is one of the genuine advantages of this lock in a household where not everyone wants to learn a menu. The CEL and CEL2 leversets work differently, with a programmed auto-lock delay.
Yes - set the thumbturn vertical and the CDL2 behaves as an ordinary passage lever: press and walk through, no code needed. Turn it back to horizontal when you want the door securing itself again. Because the setting lives on the inside face, only someone already inside can put the lock into passage mode.
Enter the code, wait for the green light, then turn the lever. People who turn the lever too early assume the code failed when it did not. If the light is not green, re-enter the code rather than forcing the lever. General troubleshooting: Buyers Guide Ch12.
Power, Batteries and Backup Entry
The CDL2 leverset is the one product in the Carbine CEL, CEL2 and CDL2 family that runs on 4 x AAA. Everything else in the range uses AA. It catches people out at the shop counter, so buy AAA spares and keep them with the lock's paperwork rather than assuming the batteries in the drawer will fit. Background on battery life in Australian conditions: The realities of electronic door locks.
Two signals. The button light turns yellow, and when a code is entered the indicator flashes red and green four times with four beeps. Treat either as your cue to change all four cells at once - do not mix an old cell with three new ones. More on what to expect over a lock's life: How long do digital door locks last?
You use the key. The CDL2 ships with an LKW9 (Silca LW5) six-pin cylinder and two mechanical keys, so a flat lock is an inconvenience rather than a lockout - provided the key is somewhere you can reach it. Keep it off-site or in a key safe, not inside the door it opens. See mechanical key override explained, and browse key storage if you need somewhere to put it.
The cylinder is an LKW9 (Silca LW5) six-pin, keyed to a five-pin key, so extra keys are a straightforward cut for any locksmith. It is a standard commercial keyway rather than a restricted one, so if you need restricted or patented keying, talk to us before you buy. Related: keys and key blanks for smart locks.
Fit, Door Preparation and Installation
A 54mm bore through the face, a 25mm hole through the door edge for the latch, and a backset of either 60mm or 70mm - the supplied latch adjusts between the two. The template also marks door thicknesses of 35, 40, 45 and 51mm. If your door already carries a standard cylindrical lockset, the holes are usually already there. Measure first: how to measure your backset · Buyers Guide Ch02: door prep.
No. One part number covers both. The lock leaves the factory set for a right swing door and the installation sheet gives the steps to change it to a left swing on site, with no extra parts. That is genuinely useful on a job where the door turns out to be handed the other way. See how to work out your door handing.
Check three things in order: the latch backset setting, the spindle alignment, and the connecting cable between the two modules. The cable seats with the metal side facing outward, and a pinched or half-seated plug is the single most common cause of a lock that powers up but will not operate. Three screw lengths are supplied - 27mm, 20.5mm and 19mm - and using the wrong one can bind the assembly. See three common DIY installation mistakes, or book a hand: site survey and installation.
No on both counts. The CDL2 leverset takes a 60mm or 70mm backset only, and a door between 35mm and 51mm thick. A 127mm backset latch cannot be fitted to this lock, so a wide-stile door needs a different product - bring us the measurements and we will tell you what does fit. See standard backset sizes.
No. The CDL2 carries no fire rating, so it must not be fitted to a fire-rated door assembly. Within the Carbine range the fire-rated options are the CEL2-3IN1 Fire Rated leverset and the CEL2-BT Fire Rated leverset. Read this first if the door is in an apartment block: Buyers Guide Ch05: identifying a fire door · fire door smart locks.
Carbine has moisture and salt spray tested the lock, but no test figure is quoted for the CDL2, so we will not put a number on it. Treat salt spray results generally as laboratory cabinet tests rather than a warranty for coastal service, and expect any keypad lock within a few kilometres of the surf to want rinsing and a look over each year. Honest brand comparison: Lockwood vs Borg vs Carbine - corrosion · coastal environments and lock life · Ch11: AS 4145.
Choosing Between the Carbine Models
The leverset is the door's working handle: press the lever and walk through. The CDL2 deadbolt is a bolt above a separate handle, and it holds ten codes rather than twenty. Plenty of Queensland entry doors end up with both - a latching lockset for daily use and a deadbolt above it. See secondary locks and the one-penetration principle.
Not this lock. The CDL2 has no RFID and no NFC. Step up to the CEL-3IN1 leverset or the CEL2-3IN1 leverset, and pair it with a CEL-RFID card, fob, sticker or wristband. Or browse every card and fob lock we stock.
Not on the CDL2 - it is a standalone lock with no Bluetooth, no Wi-Fi and no app. For phone-managed codes in the Carbine range you want a CEL2-BT leverset, which runs on Carbine Connect - and note that Carbine Connect is Bluetooth only, so you need to be at the door. There is no remote unlock. If you want true remote access, look at a Wi-Fi lock and read which platform is right for you.
For most households, yes. The CDL2 removes the key from daily use, costs less than the RFID and Bluetooth models, and has fewer things to learn or go wrong - the trade is that there is no card, no app and no log. If the door is a rental turning over guests every few days, the app models earn their extra cost. See Ch01: smart vs connected · choosing the right electronic lock.
Related products, guides and chapters
Carbine CDL2 and CEL range: CDL2 Digital Deadbolt · CEL-3IN1 Leverset Satin Nickel · CEL-3IN1 Leverset Matte Black · CEL2-3IN1 Leverset Satin Nickel · CEL2-3IN1 Leverset Matte Black · CEL2-3IN1 Deadbolt Satin Nickel · CEL2-3IN1 Deadbolt Matte Black
Fire rated and Bluetooth options: CEL2-3IN1 Fire Rated Satin Nickel · CEL2-3IN1 Fire Rated Matte Black · CEL2-BT Leverset Satin Nickel · CEL2-BT Leverset Matte Black · CEL2-BT Fire Rated Satin Nickel · CEL2-BT Fire Rated Matte Black · CEL2-BT Deadbolt Satin Nickel · CEL2-BT Deadbolt Matte Black
RFID credentials for the CEL and CEL2 locks: MIFARE Card · Key Fob · Ultra Fob · Phone Sticker · Silicone Wristband
Buyer's Guide chapters: Ch01 What Is a Smart Lock · Ch02 Measuring Your Door · Ch03 Access Methods · Ch04 Door Type Compatibility · Ch05 Fire Door Smart Locks · Ch10 Carbine Brand Profile · Ch11 Australian Standards · Ch12 Installation and Troubleshooting · Ch13 Smart Lock FAQ · Ch15 App Platforms
Blog reading: Carbine CEL & CDL Range Buyer's Guide · Carbine Connect Platform Guide · Mechanical Key Override on Smart Locks · How Long Do Digital Door Locks Last · The Realities of Electronic Door Locks · Measuring Your Lock Backset · Understanding Door Handing in Australia · Smart Lock Not Locking · Check Screen Door Clearance · What Is Bolt Throw · Lockwood vs Borg vs Carbine · Digital Door Lock - The Smarter Way
Browse by category: All Carbine products · PIN Code locks · Locks with a backup key · Internal office and bedroom doors · All smart locks · Tubular latches and bolts · Key storage
Not sure? Advice and Installation · Get a qualified locksmith recommendation
What's in the Box - CDL2-SL8SNKIT / CDL2-SL8MBKIT Kit
- 1 x exterior module with membrane keypad
- 1 x interior lever housing with thumbturn
- 1 x tubular latch (60-70mm adjustable backset)
- 1 x LKW9 (Silca LW5) keyway cylinder
- 2 x mechanical keys
- 1 x user manual and installation guide
- 1 x set of fixing screws (27mm, 20.5mm and 19mm)
- 4 x AAA alkaline batteries (Duracell Procell)
Carbine CDL2 Leverset - Door Preparation & Dimensions
For full door preparation template, see the Installation Specs tab. Buyers Guide Ch02: Measuring Your Door · Installation Guide (PDF)
Carbine CDL2 Leverset - Installation Specifications
Three screw lengths are supplied - 27mm, 20.5mm and 19mm. The door edge takes a 25mm latch bore and the face takes a 54mm bore, with the backset set to either 60mm or 70mm. The connecting cable seats with the metal side facing outward, and the sheet also covers the drive-in latch option. See: common DIY installation mistakes · Advice and Installation
For the full PDF, see the PDF Files tab. The lock ships Right Swing by default; handing reversal procedure is shown on page 1. See: Buyers Guide Ch12: Installation & Troubleshooting · field-reversible handing explained
PDF Files - Carbine CDL2 Leverset
Everyday use and programming - auto-lock and passage mode via the thumbturn, 20 user codes (4-8 digits), keypad lockout after 4 wrong entries, vacation mode, volume and troubleshooting, including the low battery warning.
Parts and screws, door preparation template (54mm bore, 60mm or 70mm backset), strike and jamb dimensions, cable connection and how to change the handing - the lock ships set for right swing doors.
Carbine's problem, cause and fix tables for its CEL-3in1 leverset and deadbolt - unresponsive keypad, battery and cable tips, programming problems, deadbolt handing and factory reset. Written for the CEL-3in1 range; it does not name the CDL2.
Carbine Warranty
Carbine is a flagship brand of Davcor Group Pty Ltd (ABN 95 003 562 598) - an Australian manufacturer, designer, and wholesale distributor of residential and commercial locking hardware. Engineered in collaboration with working locksmiths, Carbine products focus on high security, versatility, and ease of installation.
Davcor distributes Carbine through seven specialist divisions, including Lock and Key Co. - Davcor's dedicated trade distribution arm supplying locksmiths and the security industry across Australia, New Zealand, and beyond. Whether you purchased your Carbine product through Lock and Key Co., another trade channel, or directly through us, the same Davcor warranty applies.
All Carbine products are guaranteed by Davcor Group Pty Ltd to be free from defects in materials and workmanship from the date of original purchase, for the period applicable to the specific product category (refer to the Warranty Period table below). This warranty covers replacement of product only.
Warranty Summary
Warranty Periods by Product Category
Source: Davcor Warranty Against Defects - Appendix A. Warranty period runs from the date of original purchase.
How to Make a Claim
- Contact Terry's Tradies Pty Ltd (the place of purchase) in writing as soon as the defect becomes apparent - and no later than 14 days after the end of the applicable warranty period.
- Include in your written claim: a description of the defect, the date of supply, your contact details, and satisfactory proof of purchase.
- Do not return the product until a return authorisation number has been issued by Davcor. If return is required, the product must be in its original, complete, and saleable packaging.
- Davcor will test and assess the product. No claim is valid unless Davcor has confirmed a defect is present.
- Once a valid claim is confirmed, Davcor will - at its discretion - repair the defect, replace the product, or supply an equivalent product. If repair or replacement cannot be completed within a reasonable time, you may request a full refund, provided the product has been returned.
Delivery inspection: If you believe a product is defective or incorrectly supplied at the time of delivery, telephone notice must be given within 72 hours of receipt, with written notice (including full particulars) within 14 days of the invoice date.
Exclusions
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and to compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. The Carbine/Davcor express warranty operates alongside and in addition to your rights under the Australian Consumer Law.
