Carbine CEL2-3IN1 Fire Rated Leverset with RFID and Key Override - Matte Black
At A Glance
At A Glance
PIN Code
RFID / NFC
Mechanical Key
BluetoothNot Available
FingerprintNot Available
The Carbine CEL2-3IN1-SL8MB-FRKIT is the dedicated fire door installation kit for the CEL2-3IN1 leverset, providing three access methods: touchscreen PIN code, RFID/NFC credential, and mechanical key override. It stores up to 100 combined user codes and RFID credentials in a shared pool, and is specifically packaged for certified installation on fire-rated door assemblies. No app, Bluetooth, gateway, or internet connection is required.
The leverset is designed to IP54 standards and is NCC compliant. It is certified for use on Firecore fire-rated door systems. The Firecore fire assessment report is available as a PDF download below. Always verify current certification status and confirm that all other fire door hardware is rated and compatible before installation. See: Buyers Guide Ch05: Fire Door Smart Locks · Fire door types and smart lock certification.
If Bluetooth app management is also required on a fire door, see the CEL2-BT-SL8MB-FRKIT. For non-fire door applications, see the standard CEL2-3IN1-SL8MBKIT. A Satin Nickel variant (CEL2-3IN1-SL8SN-FRKIT) is also available.
Firecore: FRT230184 DHAR2.0 (Warringtonfire) - Firecore TVC30 (37mm door) FRL -/60/30; Firecore TVC40 (47-48mm door) FRL up to -/120/30; valid to 20/12/2028.
Confirm that all other hardware in the fire door assembly - hinges, door closer, intumescent seals, and strike - is also fire rated and compatible with the door system. See: Fire rating certificates · Apartment fire doors on the Gold Coast
Usually same day if ordered before 11am AEST (excluding weekends and Qld public holidays)
Available Finish Options
Matte Black
(This Product)
CEL2-3IN1-SL8MB-FRKIT
Finish does not affect function, compliance, or fire rating.
Key Features
- Dedicated fire door installation kit - certified for Firecore fire-rated door assemblies.
- Three access methods: touchscreen PIN code, RFID/NFC credential, and mechanical key override.
- Stores up to 100 combined user codes and RFID credentials (shared pool) - up from 25+25 on the original CEL-3IN1.
- Compatible with Mifare 13.56MHz RFID cards, FOBs, wristbands, stickers, and NFC-enabled smartphones.
- Standalone operation - no app, Bluetooth, gateway, or internet required.
- New lower-profile escutcheon with improved touchscreen and motor function - CEL2 generation.
- Guiding code, double authorisation, vacation mode, passage mode, auto-lock 5-99 seconds.
- NCC compliant SL8 lever. IP54 rated. ANSI Grade 2.
- Fits standard 54mm lockset hole; door 35-51mm; backset 60-70mm adjustable.
Access Methods
Works on 13.56MHz Mifare NFC (ISO14443 Type A) - RFID cards, FOBs, wristbands, stickers, and most NFC-enabled Android phones. Australian Mifare transit cards (Go card, Opal, Myki, SmartRider, MyWay, metroCard) are compatible. Visa PayWave and Mastercard PayPass are NOT compatible (ISO14443 Type B). If your phone's NFC chip is incompatible, a Mifare RFID sticker on the back of the phone is the recommended workaround. See: Carbine CEL RFID Application List (PDF) · Buyers Guide Ch03: Access Methods
Suitable Uses
- Firecore fire-rated door assemblies in residential, strata, and commercial buildings requiring PIN and RFID access. See: Buyers Guide Ch05: Where are fire doors required?
- Apartment and strata fire-rated entry doors with NCC lever compliance requirements. See: Apartment fire doors on the Gold Coast - compliance
- Emergency exits and fire escape corridors requiring certified hardware with RFID card access for residents and RFID override for management.
- Fire-rated doors where a simple standalone solution is preferred and Bluetooth app management is not required.
- Sites requiring RFID card handover for cleaners, contractors, or regular service personnel on a fire-rated entry door.
See also: Asbestos in Gold Coast apartment fire doors · Buyers Guide Ch02: Measuring Your Door · Check clearance between door and security screen · Fire door smart locks (category) · PIN code smart locks · RFID and card access smart locks · Smart locks with a backup key
What's in the Box
- 1 x exterior electronic module with touchscreen keypad
- 1 x interior lever handle assembly
- 1 x tubular latch (60-70mm adjustable backset)
- 1 x C4 keyway cylinder (6-pin, keyed to 5-pin key)
- 2 x mechanical keys
- 2 x RFID key cards
- 1 x user manual and installation guide
- 1 x set of fixing screws
- 4 x AA alkaline batteries (Duracell Procell)
Note: When installing on fire-rated doors, confirm all supplementary hardware (hinges, closer, seals, strike) is fire rated and compatible with the door system and FRL.
Accessories & Retrofit Plates
Carbine CEL / CEL2 / CDL2 - Complete Product Family
CEL2-BT deadbolt: RFID not available - Bluetooth and PIN only. CDL2: membrane keypad, no RFID. All KIT numbers include batteries. For a full model comparison: Carbine CEL & CDL Buyer's Guide - CEL2-3IN1 FR Kit
Full Specifications
Key Dimensions
Battery, Power & Backup Access
- Powered by 4 x AA alkaline batteries (Duracell Procell recommended). Do not use lithium or rechargeable batteries.
- Battery life approx. 5,000 openings. Low battery warning via LED and audible tone before depletion.
- Mechanical key override provides physical backup entry at all times - critical on fire doors where loss of electronic access must never prevent egress. See: How long do digital door locks last?
Frequently Asked Questions
Both the standard and FRKIT variants use the same lock mechanism and carry fire rating certifications. This kit (FRKIT) is specifically packaged for certified fire door installation and includes fire certification documentation. For non-fire door applications, the standard CEL2-3IN1-SL8MBKIT is appropriate. See: Buyers Guide Ch05: Fire Door Smart Locks
No. This is a standalone model - PIN and RFID only. For Bluetooth app management on a fire-rated door, see the CEL2-BT-SL8MB-FRKIT. Not sure which connectivity you need? See: Buyers Guide Ch08: Gateway Comparison
The CEL2-3IN1 fire rated leverset is certified for Firecore door assemblies (FRT230184 DHAR2.0, Warringtonfire - TVC30 FRL -/60/30; TVC40 up to FRL -/120/30, valid 20/12/2028). The Firecore assessment report is provided as a PDF download below. Always verify all certificates are current before specifying. See: Fire door types and smart lock certification
Most NFC-enabled Android phones with Mifare support work. Visa PayWave and Mastercard PayPass are not compatible (ISO14443 Type B). If incompatible, use a Mifare RFID sticker adhered to the back of the phone. See: Carbine CEL RFID Application List (PDF) and Buyers Guide Ch03: RFID access methods
No. Outside these ranges the lock is not compatible. See: Buyers Guide Ch02: Backset · How to measure your backset
Additional Information
The lock certification covers the lockset only. All other hardware in the fire door assembly must also be rated and compatible - hinges, door closer, intumescent seals, and strike. Confirm the complete hardware schedule with your fire door supplier or certifier before ordering. Verify all fire rating certificates are current before installation. See: Fire door types and smart lock certification · Fire rating certificates · Apartment fire doors on the Gold Coast
Fire doors in older Gold Coast apartment buildings (pre-1990) may contain asbestos in the core or surrounding frame. Do not drill or cut without confirming the door material first. See: Asbestos in Gold Coast apartment fire doors
The connecting cable between the exterior and interior modules must be correctly seated in the mounting plate channel. Incorrect routing is the most common installation failure - it causes an unresponsive keypad or a battery cover that won't seat correctly. Check cable routing first if the keypad stops responding after installation. See: 3 common DIY smart lock installation mistakes
The factory default programming code is 12345678. Change it to a private code immediately after installation. Issue separate user codes or RFID cards for day-to-day access; never share the programming code with tenants or users. See: The realities of electronic door locks
Terry's Locksmiths offers supply and installation on the Gold Coast, including fire door assessments. For self-installation: Buyers Guide Ch12: Installation & Troubleshooting
Warranty
Carbine products are backed by Davcor Group Pty Ltd, the Australian manufacturer and owner of the Carbine brand, distributed locally through Lock and Key Co. Warranty periods vary by product category:
- Up to 15 years - mechanical hardware, door hardware, cabinet furniture, utility and window locks
- 10 years - padlocks and mechanical digital locks
- 5 years - cylinders and keys
- 12 months - electronic and digital locks, locksmith tools and supplies
Download PDF Resources
Two-page sheet - parts and screws, door preparation template (54mm bore, 60mm or 70mm backset), 70 x 25mm strike and jamb dimensions, latch and mounting plate fitting, cable connection, batteries and the optional lever swap.
Two-page programming sheet - auto-lock and passage mode, unlocking by code, RFID card or key, 100 combined user codes and cards, single-use codes, vacation mode, volume, # key mode switching, double authorisation and factory reset.
Ten-page brochure for the standard CEL2 range - leverset, deadbolt and 2-hour fire rated leverset - covering entry options, 54mm hole fit, 35-51mm doors, 60-70mm backset, finishes and the retrofit plates for replacing an old CEL-3IN1.
14-page problem, cause and fix guide for CEL2-3in1 and CEL-3in1 leversets and deadbolts - unresponsive keypad, overheating, passage mode, motor and programming faults, deadbolt handing, Bluetooth issues with the Carbine Connect app, battery tips and factory reset.
Warringtonfire assessment of the CEL2-3IN1-SL8SN electronic lockset in Firecore doorsets - FRL -/120/30 in 47mm and 48mm TVC40 core doors, and -/60/30 in a 37mm TVC30 core door. Valid to December 2028.
Carbine's application list for CEL RFID credentials across its digital lock range.
Carbine CEL2-3IN1 Fire Rated Leverset - FAQ, Setup & Owner's Guide
Answers to the questions buyers, installers and building managers ask about the CEL2-3IN1-SL8MB-FRKIT fire rated leverset. For general smart lock questions see the Buyers Guide Ch13: Smart Lock FAQ, and for how this model sits in the wider Carbine range see the Carbine CEL & CDL Buyer's Guide.
Fire Rating & Compliance
It is assessed for Firecore fire-rated doorsets under Warringtonfire report FRT230184 DHAR2.0: FRL -/60/30 in a 37mm TVC30 Firecore core door and up to FRL -/120/30 in 47-48mm TVC40 Firecore core doors, valid to 20/12/2028. Always confirm the certificate is current before you specify it. See: Ch05: Fire door core types · Fire door types and certification
Yes. The Warringtonfire assessment was run on the CEL2-3IN1-SL8SN lockset, and the fire performance comes from the lock body, latch and strike, not the finish. Matte Black and Satin Nickel share the same mechanism, so the finish does not change the fire rating.
Only the lockset is covered by this certification. Every other item in the fire door assembly - hinges, door closer, intumescent seals and strike - must also be fire rated and compatible with the door system and its FRL. Confirm the full hardware schedule with your fire door supplier or certifier. See: Apartment fire doors: the one-penetration principle
Take care. Fire doors in older Gold Coast buildings (pre-1990) can contain asbestos in the core or frame, so confirm the door material before drilling or cutting. See: Asbestos in Gold Coast apartment fire doors
Access, Codes & RFID
Up to 100 credentials in total, drawn from a single shared pool of PIN codes and RFID cards - so you might set 60 codes and 40 cards, or any mix up to 100. That is a big step up from the 25 codes plus 25 cards on the original CEL-3IN1. Codes are 4-8 digits, and single-use codes are also supported.
It reads 13.56MHz Mifare (ISO14443 Type A) media - cards, fobs, wristbands, stickers, and most NFC-enabled Android phones. Australian Mifare transit cards (Brisbane Go card, Sydney Opal, Victoria Myki, Perth SmartRider, Canberra MyWay, Adelaide metroCard) work. Visa payWave and Mastercard payPass do not (they are ISO14443 Type B). If your phone's NFC chip is not compatible, a Mifare RFID sticker on the back of the phone is the recommended workaround. See: Ch03: RFID access
Only original Carbine RFID cards are guaranteed. Other Mifare cards will often work, but if that card is later re-programmed in a different reader its settings can change and stop it operating the lock - so keep a dedicated card for the door rather than sharing one across systems.
It is a two-factor mode: when enabled, the door only opens when a valid RFID card and a PIN code are both presented, not either one alone. It is useful on higher-security fire-rated entries where a lost card on its own should not grant entry.
No. This is a standalone lock - PIN, RFID and mechanical key only, with no app, Bluetooth, gateway or internet connection. If you need Bluetooth app management on a fire door, see the CEL2-BT-SL8MB-FRKIT. Not sure which connectivity you need? See Ch08: Gateway comparison.
Power & Batteries
Four AA alkaline batteries (Duracell Procell recommended and supplied in the kit), giving roughly 5,000 openings. A low-battery warning sounds and shows on the keypad before they go flat. Do not use lithium or rechargeable AA batteries. See: How long do digital door locks last?
The mechanical key override always works, independent of the electronics - which is exactly why a key cylinder is critical on a fire door: loss of electronic power must never prevent egress or entry. A C4 keyway cylinder and two keys are included.
Fit & Installation
It suits doors 35-51mm thick with an adjustable 60-70mm backset and a standard 54mm cylindrical lockset bore. A 127mm backset is not supported. Measure before ordering - outside these ranges the lock will not fit. See: Ch02: Backset · How to measure your backset
Check the cable routing. The connecting cable between the exterior and interior modules must sit correctly in the mounting-plate channel; a pinched or mis-seated cable is the most common cause of an unresponsive keypad or a battery cover that will not close. See: 3 common DIY installation mistakes
Yes. Change the factory programming code (12345678) to a private code immediately after installation, then issue separate user codes or RFID cards for day-to-day access. If you ever need to start again, a factory reset (remove one battery, hold SET while refitting it) restores the programming code to 1-2-3-4-5-6-7-8. See: The realities of electronic door locks
Passage (free-entry) mode holds the latch open for busy periods - after unlocking, hold the [#] key for one second to toggle it on. Auto-lock re-secures the door automatically after a set delay, adjustable from 5 to 99 seconds; it is disabled by default and must be turned on.
Choosing the Right Model
Both use the same lock mechanism. This FRKIT is packaged for certified fire door installation and ships with the fire certification documentation. For non-fire doors, the standard CEL2-3IN1-SL8MBKIT is the right choice.
Yes - the CEL2-3IN1-SL8SN-FRKIT is the same fire rated kit in Satin Nickel. The finish does not affect function, compliance or fire rating.
Related products, guides and chapters
This range: CEL2-3IN1-SL8MBKIT (standard, Matte Black) · CEL2-3IN1-SL8SN-FRKIT (fire rated, Satin Nickel) · CEL2-BT-SL8MB-FRKIT (Bluetooth fire rated) · CEL2-3IN1-DBMBKIT (deadbolt)
Buyer's Guide chapters: Ch05: Fire door smart locks · Ch03: Access methods · Ch02: Measuring your door · Ch11: Standards & IP ratings · Ch12: Installation & troubleshooting
Blogs: Carbine CEL & CDL range guide · Fire door types & certification · Fire rating certificates · Apartment fire doors: what is compliant · Asbestos before drilling · The realities of electronic door locks
Browse: Fire door smart locks · PIN code smart locks · RFID & card access smart locks · Smart locks with a backup key
What's in the Box - CEL2-3IN1-SL8MB-FRKIT
Carbine CEL2 Leverset - Dimensions
How to measure your backset · Buyers Guide Ch02: Measuring Your Door
Carbine CEL2-3IN1 - Product Brochure
PDF Files - Carbine CEL2-3IN1 Fire Rated Leverset
Two-page sheet - parts and screws, door preparation template (54mm bore, 60mm or 70mm backset), 70 x 25mm strike and jamb dimensions, latch and mounting plate fitting, cable connection, batteries and the optional lever swap.
Two-page programming sheet - auto-lock and passage mode, unlocking by code, RFID card or key, 100 combined user codes and cards, single-use codes, vacation mode, volume, # key mode switching, double authorisation and factory reset.
Ten-page brochure for the standard CEL2 range - leverset, deadbolt and 2-hour fire rated leverset - covering entry options, 54mm hole fit, 35-51mm doors, 60-70mm backset, finishes and the retrofit plates for replacing an old CEL-3IN1.
14-page problem, cause and fix guide for CEL2-3in1 and CEL-3in1 leversets and deadbolts - unresponsive keypad, overheating, passage mode, motor and programming faults, deadbolt handing, Bluetooth issues with the Carbine Connect app, battery tips and factory reset.
Warringtonfire assessment of the CEL2-3IN1-SL8SN electronic lockset in Firecore doorsets - FRL -/120/30 in 47mm and 48mm TVC40 core doors, and -/60/30 in a 37mm TVC30 core door. Valid to December 2028.
Carbine's application list for CEL RFID credentials across its digital lock range.
Carbine Warranty
Carbine is a flagship brand of Davcor Group Pty Ltd (ABN 95 003 562 598) - an Australian manufacturer, designer, and wholesale distributor of residential and commercial locking hardware. Engineered in collaboration with working locksmiths, Carbine products focus on high security, versatility, and ease of installation.
Davcor distributes Carbine through seven specialist divisions, including Lock and Key Co. - Davcor's dedicated trade distribution arm supplying locksmiths and the security industry across Australia, New Zealand, and beyond. Whether you purchased your Carbine product through Lock and Key Co., another trade channel, or directly through us, the same Davcor warranty applies.
All Carbine products are guaranteed by Davcor Group Pty Ltd to be free from defects in materials and workmanship from the date of original purchase, for the period applicable to the specific product category (refer to the Warranty Period table below). This warranty covers replacement of product only.
Warranty Summary
Warranty Periods by Product Category
Source: Davcor Warranty Against Defects - Appendix A. Warranty period runs from the date of original purchase.
How to Make a Claim
- Contact Terry's Tradies Pty Ltd (the place of purchase) in writing as soon as the defect becomes apparent - and no later than 14 days after the end of the applicable warranty period.
- Include in your written claim: a description of the defect, the date of supply, your contact details, and satisfactory proof of purchase.
- Do not return the product until a return authorisation number has been issued by Davcor. If return is required, the product must be in its original, complete, and saleable packaging.
- Davcor will test and assess the product. No claim is valid unless Davcor has confirmed a defect is present.
- Once a valid claim is confirmed, Davcor will - at its discretion - repair the defect, replace the product, or supply an equivalent product. If repair or replacement cannot be completed within a reasonable time, you may request a full refund, provided the product has been returned.
Delivery inspection: If you believe a product is defective or incorrectly supplied at the time of delivery, telephone notice must be given within 72 hours of receipt, with written notice (including full particulars) within 14 days of the invoice date.
Exclusions
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and to compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. The Carbine/Davcor express warranty operates alongside and in addition to your rights under the Australian Consumer Law.
