Borg Mech-Digital BL5401DDAECP *Keypad Only* AS1428.1 Compliant Flat Bar Lever – Satin Stainless – Easicode Pro
This product is supplied as a keypad unit only. It does not include a latch, inside handle, strike plate, spindle, or fixing screws. It is designed for replacing a worn or damaged outside keypad on an existing BL5401 installation, or for custom installations where the inside hardware and latch are sourced separately. For the complete lock, see the BL5401SSDDAECP complete DDA ECP lockset. Read why genuine keypad-only spares beat hardware-store imitations. Refer to the drilling template PDF for hole placement.
The Borg BL5401 DDA ECP Keypad Only (BL5401KSSDDAECP) is a replacement outside keypad unit with DDA compliant flat bar lever, Easicode Pro on-door code change, in satin stainless finish. It uses the same BL5401 DDA lever and ECP code change mechanism as the complete lock version, and sits in the Borg mechanical digital lock range.
This product is a spare part and replacement unit. If you need a complete lock including inside handle, latch, and all fixings, see the complete lock BL5401SSDDAECP (ECP satin stainless) or BL5401DDAMGPROECP (ECP Marine Grade Pro black).
Usually same day if ordered before 11am AEST (excluding weekends and Qld public holidays)
Flat bar lever compliant with BCA AS1428.1-2009. Suitable for disability access doors, accessible toilet facilities, and BCA-compliant applications. See the DDA options in our commercial mech-digi guide and the DDA & NDIS accessibility guide. Lever compliance relates to the handle design only.
The PIN can be changed while the unit is installed – no lock removal. Insert the code change key over the Φ button, rotate 90° clockwise, hold, press C to clear, enter new digits, confirm, then release. See the full 5000-series ECP code-change procedure.
Entirely mechanical. No power source, no wiring, and no battery maintenance at any point.
Key Features
- DDA compliant flat bar lever – AS1428.1-2009.
- Easicode Pro (ECP) on-door code change – no lock removal required.
- Satin stainless finish.
- Over 1,000 non-sequential code combinations.
- 8mm square drive spindle (spindle not included).
- Suitable for replacing worn keypad on existing BL5401 installations.
- Fully mechanical – no batteries, no wiring.
What's in the Box (Keypad Only)
- Borg BL5401 ECP DDA keypad unit with flat bar lever (satin stainless) – keypad only
- Easicode Pro code change key
- Code change deactivation plug (optional)
- Free passage deactivation plug (optional)
- Hex wrench (Allen key)
- Handle screw rubber grommet
- Note: Latch, inside handle, spindle, strike plate, and all fixing screws are NOT included – source separately
Compatible Complete Lock Products
Borg BL5401 DDA Series – Product Family
All BL5401 DDA models use the AS1428.1-2009 compliant flat bar DDA lever. All are fully mechanical with no batteries. All full-lock models are fire rated to AS 1905.1-2005 (up to 4 hours depending on doorset).
ECP = Easicode Pro on-door code change. MG Pro = Marine Grade Pro – 316 SS internals – 1,000hr salt spray tested. Keypad-only models require a compatible latch and inside handle sourced separately.
Dimensions
Dimensional drawing for the BL5400 series – outside keypad unit and inside DDA flat bar lever handle. Confirm door thickness before ordering.
Full Specifications
Frequently Asked Questions
The BL5401KSSDDAECP includes the outside keypad unit only – with DDA flat bar lever and Easicode Pro code change key. It does not include a latch, inside handle, spindle, strike plate, or fixing screws. All of these must be sourced separately or reused from the existing installation being replaced. For the complete lock, see the BL5401SSDDAECP complete DDA ECP lockset.
The BL5401 uses a flat bar lever compliant with BCA AS1428.1-2009 (Design for Access and Mobility). This lever requires significantly less grip force and torque than a round bar lever, making it suitable for users with limited hand strength or dexterity. It is the correct lever type for disability access doors, accessible toilet facilities, and any application where BCA accessibility compliance is required for the locking hardware. See our commercial mech-digi DDA options. Lever compliance relates to the handle design only and does not imply full building access compliance for the installation.
With the door open, enter the current code. Insert the code change key over the Φ button, rotate it 90° clockwise, then press and hold fully. Press C to clear, enter the new code digits, press all digits again to confirm, then release and remove the key. Press C or rotate the lever to finalise. Test at least 5 times before closing the door. See the full 5000-series ECP procedure. The code is non-sequential — if set to 1234, entering 4321 or any order will open the lock (a defining trait of mechanical digital locks).
This keypad unit is compatible with the BL5401 series lock body configuration. The 8mm square drive spindle suits most leading brands of tubular latch and mortice lock case. Always confirm spindle length and compatibility with your specific lock body before ordering. Refer to the drilling template PDF (in the PDF Downloads section) for correct hole placement.
Yes. All BL5401 units are factory set for right-hand doors. To change: remove the rubber grommet at the base of the keypad handle, use the included hex wrench to remove the grub screw, rotate the handle 180° and refit. Repeat for the inside handle. Handing is determined from the outside of the door: right hand = hinges on the right; left hand = hinges on the left, regardless of swing direction.
All Borg locks are warranted against mechanical defects in materials and workmanship under normal use and service for a minimum of 12 months from date of sale. The warranty does not cover damage arising from misuse, vandalism, or improper installation. The lock must not be dismantled — doing so will invalidate the warranty.
What's In The Box – Borg BL5401KSSDDAECP
- Borg BL5401 ECP DDA keypad unit with flat bar lever (satin stainless) – keypad only
- Easicode Pro code change key
- Code change deactivation plug (optional)
- Free passage deactivation plug (optional)
- Hex wrench (Allen key)
- Handle screw rubber grommet
- Note: Latch, inside handle, spindle, strike plate, and all fixing screws are NOT included – source separately
Borg BL5401 DDA Series – Real Installations
Borg BL5400 Series – Dimensions
Borg BL5000 Series – Product Brochure
Borg Locks Warranty
Borg products sold in Australia are covered against mechanical defects in materials and workmanship under normal use and service. Warranty claims are handled by Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries.
Warranty Summary
What the Warranty Covers
- Mechanical defects in materials and workmanship
- Defects arising under normal use and service conditions
- Repair or replacement of defective units at the discretion of the Australian distributor (LSC)
What the Warranty Does Not Cover
- Damage arising from misuse, vandalism, or abuse
- Damage resulting from improper installation
- Locks that have been dismantled - dismantling invalidates the warranty
- Normal wear and tear
- Cosmetic damage not affecting function
How to Make a Claim
- Contact Terry's Tradies Pty Ltd first if you purchased through us or one of its associated trading names - we will assess the issue and manage the warranty process with LSC on your behalf. You do not need to contact LSC or Borg Locks UK directly.
- Have your proof of purchase ready (receipt or order confirmation).
- Warranty claims for Borg products in Australia are processed through LSC, the authorised Australian importer and distributor. Where an item is returned to LSC, freight charges must be prepaid and the item returned within the warranty period.
- If LSC finds the returned item to be defective, it will be repaired or replaced, and a detailed assessment report is provided to the customer after examination.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. The Borg manufacturer warranty above operates alongside - and does not limit - these statutory rights.
