HID Signo Wall Spacer 25.4 mm (1 Inch) - Suits 20 and 20K Series Readers
The HID Signo Wall Spacer 25.4 mm (1 Inch) (20K10 in black, 20S10 in silver) sits behind an HID Signo 20 or Signo 20K reader and stands it 25.4 mm off the mounting surface. Its job is read range: HID recommends a spacer whenever a Signo reader is mounted on or near metal, including a metal junction box, because metal behind the reader shortens the distance at which it reads a card.
This spacer is made for the Signo 20 and 20K only - the 45 mm wide bodies. The Signo 40 and 40K take the spacer for 40 and 40K readers. Black and silver are both sold from this listing; choose from the Colour option. Silver is a special order.
Black usually ships within 24 hours (excludes weekends and Queensland public holidays). Silver is a special order - contact us for an estimated dispatch time before you order.
Key Features
- Made for metal surfaces - HID recommends a spacer whenever a Signo reader is mounted on or near metal, including a metal junction box. Metal behind the reader cuts its read range, and the spacer moves the reader clear of it.
- 25.4 mm (1 inch) deep - the deeper of the two spacer sizes HID makes for these readers.
- Plastic - HID recommends plastic spacers to improve read performance on metal mounting surfaces.
- Black or silver - 20K10 is black and 20S10 is silver. Silver matches the trim plate the reader ships with; black matches the black mounting plate.
- Sized for the 45 mm wide Signo 20 and 20K - it does not suit the 80 mm wide Signo 40 and 40K.
- Works with the reader's surface detection - the reader detects its mounting surface and recalibrates itself for read range, and HID still recommends the spacer on metal.
Compatible Readers
HID lists this spacer as 20-K-10 (black) and 20-S-10 (silver) for the Signo 20 / 20K in its Signo ordering guide (page 3). We list it without the hyphens, as 20K10 and 20S10.
What's in the Box
- 1 x HID Signo wall spacer, 25.4 mm (1 inch), in black (20K10) or silver (20S10) as chosen
HID doesn't itemise any fixings with the spacer. It adds 25.4 mm between the reader and the surface, and the screws in the reader's box are 9.5 mm (0.375 inch) and 12 mm long for a junction box and 38 mm (1.5 inch) self-tapping for a bare wall, so check your fixings before you start.
Suitable Uses
- Signo 20 and 20K readers fixed to a steel or aluminium door frame or mullion - where these narrow readers are often fitted.
- Readers mounted over a metal junction box, which HID names specifically.
- Readers on metal that are picking up cards at a shorter range than expected.
Signo 40 and 40K readers - they take the spacer made for them. Levelling an uneven wall - HID wants the reader on a flat, stable surface with or without a spacer.
Available Finish Options
Black
(This Product)
STK 20K10
Silver
(This Product)
STK 20S10
Finish selection does not affect functionality, compliance, or performance. Both colours are sold from this listing. Silver is a special order.
HID Signo Mounting Plates and Wall Spacers
HID makes a separate mounting plate for each of the four readers below, and a wall spacer for each body width. These are the ones we sell, with the reader each one fits.
Choose by reader model. If you are not sure which Signo reader you have, send us a photo and we will confirm it before you order. HID's part numbers are from its Signo ordering guide (page 3).
Full Specifications
Dimensions
Reader sizes are from HID's Signo datasheet - see the Signo 20 and Signo 20K pages. HID doesn't quote the spacer's own width and length; it is made for the 45 mm wide body.
Fitting Notes
The spacer goes between the mounting surface and the reader. The reader's own fitting steps do not change - mounting plate, wiring, then the reader hooked on and screwed to its plate. They are set out on the Signo 20 and Signo 20K pages.
- Fit it wherever the reader is on or near metal, including a metal junction box.
- Check your fixings first. The spacer adds 25.4 mm, and the screws supplied with the reader are 9.5 mm and 12 mm (junction box) and 38 mm (self-tapping) long.
- Keep to a flat, stable surface. An uneven surface can compromise the reader's IP65 rating and its tamper feature, spacer or not.
- Allow for the extra depth - the reader ends up about 45 to 47 mm proud of the surface. See Dimensions.
Frequently Asked Questions
When the reader is mounted on or near metal - a steel or aluminium door frame or mullion, or a metal junction box behind the reader. Metal behind a reader shortens the distance at which it picks up a card, and HID recommends a plastic spacer to improve it. On a non-metal surface no spacer is needed for read range.
Either - they are the same spacer in two colours. Silver matches the silver trim plate the reader ships with. Black suits a reader fitted with the black mounting plate - the 20KMP for the Signo 20 or the 20KTKMP for the Signo 20K. Choose from the Colour option. Silver is a special order, so allow extra time for it.
HID still recommends it. Surface detection lets the reader recalibrate itself to the surface it is mounted on, which helps, but the spacer is what moves the reader clear of the metal.
Yes. HID also makes a 12.7 mm (half inch) spacer for the same readers. We sell the 25.4 mm (1 inch) size.
Additional Information
- It changes how far the reader stands out. A Signo 20 goes from 19.5 mm to 44.9 mm from the surface, a Signo 20K from 21.5 mm to 46.9 mm. Check door swings, handles and anything else that passes close to the reader.
- Outdoors. The readers are IP65 rated. HID doesn't quote a separate weather rating for the spacer, and it asks for a flat, stable surface to protect the reader's own rating.
- One part, two ways of writing it. HID writes these spacers as 20-K-10 and 20-S-10. We list them as 20K10 and 20S10. They are the same parts.
- Warranty on the spacer. The lifetime cover in the warranty box below is for HID readers and credentials. HID does not list Signo wall spacers for lifetime cover, so its general hardware warranty applies - one year from HID's shipment date - alongside your rights under the Australian Consumer Law.
- Fitting is installer work. An access control reader is a job for a security installer or locksmith - see when DIY is and is not appropriate, our advice and installation page and installation across the Gold Coast. Browse our other smart lock accessories, or the rest of the HID range.
